EASY PDU METERED 0U 22KW (18)C13 (6)C19

EASY PDU METERED 0U 22KW (18)C13 (6)C19

SKU:EPDU1232M

$1,701.67 SGD
$2,889.00 SGD $1,701.67 SGD
Sale Pre-order with us via Whatsapp
Shipping calculated at checkout.

Click to WhatsApp us to confirm stock availability

View full details
Description Specifications
Management
Management
  • https/http
  • Modbus-TCP
  • Web
  • Telnet
SNMP:
  • V1
  • V2
  • V3
Miscellaneous
Environmentally Friendly Yes
Physical Characteristics
Weight (Approximate) 4.64 kg
Mount Type Rack-mountable
Rack Height 0U
Height 1506 mm
Width 62 mm
Depth 44 mm
Mounting Orientation Horizontal/Vertical/Toolless
Power Description
Input Voltage 400 V AC
Output Voltage 230 V AC
Input Current 32 A
Power Rating (Watt) 22 kW
Technical Information
Protection Type Circuit Protection
Protection Type Overload Protection
Plug/Connector Type IEC 309 32A 3P+N+PE
Phase Three Phase
Receptacle Type IEC 60320 C13
Receptacle Type IEC 60320 C19
PDU Type Metered
Receptacle Detail 18 x IEC 60320 C13
Receptacle Detail 6 x IEC 60320 C19
