APC Rack PDU 9000 Switched ZeroU 16A - Apc
Management |
Management |
|
Physical Characteristics |
Weight (Approximate) |
5.61 kg |
Form Factor |
Tower |
Mount Type |
Rack-mountable |
Rack Height |
0U |
Height |
1794 mm |
Width |
55.1 mm |
Depth |
46 mm |
Mounting Orientation |
Horizontal/Vertical/Toolless |
Power Description |
Input Voltage |
230 V AC |
Output Voltage |
230 V AC |
Input Current |
16 A |
Input Voltage Range |
220 V AC - 240 V AC |
Power Rating (VA) |
3.70 kVA |
Technical Information |
Protection Type |
Overload Protection |
Protection Type |
Circuit Protection |
Plug/Connector Type |
IEC 60309 (2P+E) 16A |
Receptacle Type |
IEC 60320 C19 |
Receptacle Type |
IEC 60320 C13 |
PDU Type |
Switched |
Locking Receptacles |
Cord Retention Bracket |
Receptacle Detail |
21 x IEC 60320 C13 |
Receptacle Detail |
3 x IEC 60320 C19 |
Plug/Connector Detail |
1 x IEC 60309 (2P+E) 16A |
