Battery Information | |
---|---|
Battery Chemistry | Lead Acid |
Number of Batteries | 1 |
Backup/Run Time (Half Load) | 21.10 Minute |
Backup/Run Time (Full Load) | 8.40 Minute |
Battery Characteristics | Maintenance-free, Sealed |
Replaceable Battery | Yes |
Typical Battery Recharge Time | 3 Hour |
Controls/Indicators | |
Status Indicators | LCD Graphics Screen |
Environmental Conditions | |
Thermal Dissipation | 317 BTU/h |
Maximum Operating Temperature | 40°C |
Maximum Operating Elevation | 3 km |
Maximum Storage Elevation | 15 km |
Sound Emission (A-Weighted) | 50 dB(A) |
Interfaces/Ports | |
Network (RJ-45) | Yes |
Serial Port | Yes |
EPO Port | Yes |
USB (HID Compliant) Port | Yes |
Miscellaneous | |
Software Included | APC Powerchute Network Shutdown Software |
Environmentally Friendly | Yes |
Physical Characteristics | |
Weight (Approximate) | 21 kg |
Form Factor | Rack-mountable |
Rack Height | 2U |
Height | 85 mm |
Width | 432 mm |
Depth | 505 mm |
Product Color | Black |
Color Family | Black |
Power Description | |
Input Voltage | 230 V AC |
Output Voltage | 240 V AC |
Output Voltage | 230 V AC |
Surge Energy Rating | 432 J |
Waveform Type | Sine Wave |
Input Voltage Range | 50 V AC - 150 V AC |
Output Frequency | 60 Hz |
Input Frequency | 70 Hz |
Load Capacity (VA) | 1 kVA |
Technical Information | |
Application/Usage | Computer |
Application/Usage | Server |
Application/Usage | Medical |
Application/Usage | IT Equipment |
Application/Usage | Industry |
Application/Usage | Voice/Data Network |
Plug/Connector Type | British BS1363A |
Plug/Connector Type | SCHUKO CEE 7 EU1-16P |
Plug/Connector Type | IEC 60320 C14 |
Receptacle Type | IEC 60320 C13 |
Number of Battery & Surge Outlets | 12 |
Transfer Time | 0 ns |
Receptacle Detail | 6 x IEC 60320 C13 |
