Battery Information | |
---|---|
Battery Characteristics | External Battery System |
Environmental Conditions | |
Thermal Dissipation | 450 BTU/h |
Maximum Operating Temperature | 40°C |
Maximum Operating Elevation | 3.05 km |
Maximum Storage Elevation | 15.24 km |
Sound Emission (A-Weighted) | 50 dB(A) |
Interfaces/Ports | |
USB | Yes |
Network (RJ-45) | Yes |
Serial Port | Yes |
EPO Port | Yes |
Management | |
Network Management | Intelligent Card Slot |
Network Management | SmartSlot |
Miscellaneous | |
Package Contents |
|
Certifications & Standards |
|
Environmentally Friendly | Yes |
Environmental Compliance | China Restriction of Hazardous Substances (China RoHS) |
Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
Physical Characteristics | |
Weight (Approximate) | 17.51 kg |
Form Factor | Tower/Rack Convertible |
Rack Height | 2U |
Height | 85 mm |
Width | 432 mm |
Depth | 590 mm |
Product Color | Black |
Color Family | Black |
Power Description | |
Input Voltage | 120 V AC |
Input Voltage | 230 V AC |
Output Voltage | 240 V AC |
Output Voltage | 220 V AC |
Output Voltage | 230 V AC |
Surge Energy Rating | 340 J |
Waveform Type | Pure Sine Wave |
Input Voltage Range | 80 V AC - 150 V AC |
Input Voltage Range | 50 V AC - 150 V AC |
Output Frequency | 60 Hz |
Output Frequency | 50 Hz |
Input Frequency | 40 Hz |
Input Frequency | 70 Hz |
Load Capacity (VA) | 1.50 kVA |
Technical Information | |
Application/Usage | IT |
Application/Usage | Voice/Data Network |
Application/Usage | Virtual Machine |
Application/Usage | Storage |
Application/Usage | Server |
Application/Usage | Network |
Application/Usage | Medical Laboratory |
Application/Usage | Light Industrial Application |
Application/Usage | Hyperconverged Infrastructure (HCI) |
Features | Audible Alarm |
Features | Built-in Bypass Switch |
Plug/Connector Type | IEC 60320 C14 |
Receptacle Type | IEC 60320 C13 |
Receptacle Detail | 8 x IEC 60320 C13 |
Warranty | |
Additional Warranty Information | 5 year repair or replace |
