Apc
SKU:SRTG10KXLI
Couldn't load pickup availability
WhatsApp us to confirm stock availability before placing your order.
View full details
| Battery Information | |
|---|---|
| Battery Chemistry | Lead Acid |
| Battery Energy | 6379.2 kJ |
| Number of Batteries | 0 |
| Backup/Run Time (Half Load) | 11 Minute |
| Backup/Run Time (Full Load) | 3.60 Minute |
| Battery Characteristics | Maintenance-free/Sealed/Leak Proof/Valve-regulated |
| DC System Voltage | 96 V DC |
| Typical Battery Recharge Time | 4 Hour |
| Controls/Indicators | |
| Status Indicators |
LCD Display Screen:
|
| Environmental Conditions | |
| Sound Emission | 55 dB |
| Thermal Dissipation | 2217.98 BTU/h |
| Maximum Operating Temperature | 40°C |
| Maximum Operating Elevation | 2.01 km |
| Maximum Storage Elevation | 15.24 km |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Serial Port | Yes |
| EPO Port | Yes |
| Management | |
| Alarm | Low Battery |
| Alarm | Overload |
| Alarm | On Battery |
| Physical Characteristics | |
| Weight (Approximate) | 81.12 kg |
| Form Factor | Rack/Tower |
| Height | 217 mm |
| Width | 440 mm |
| Depth | 620 mm |
| Power Description | |
| Output Voltage | 230 V AC |
| Output Voltage | 220 V AC |
| Output Voltage | 240 V AC |
| Waveform Type | Sine Wave |
| Input Voltage Range | 160 V - 285 V |
| Output Frequency | 60 Hz |
| Input Frequency | 70 Hz |
| Load Capacity (VA) | 10 kVA |
| Load Capacity (Watt) | 10 kW |
| Technical Information | |
| Application/Usage | Branch Office |
| Application/Usage | Server Room |
| Application/Usage | Network |
| Application/Usage | Business |
| Receptacle Type | IEC 60320 C13 |
| Receptacle Type | IEC 60320 C19 |
| Receptacle Type | Hard Wire 3-wire (H N + E) |
| Receptacle Detail | 1 x Hard Wire 3-wire (H N + E) |
| Receptacle Detail | 1 x IEC 60320 C19 |
| Receptacle Detail | 2 x IEC 60320 C20 |
