Apc
SKU:SRTG5KXLI
Couldn't load pickup availability
WhatsApp us to confirm stock availability before placing your order.
View full details
| Battery Information | |
|---|---|
| Battery Chemistry | Lead Acid |
| Hot Swappable | Yes |
| Battery Energy | 3456 kJ |
| Number of Batteries | 2 |
| Replaceable Battery | Yes |
| DC System Voltage | 96 V DC |
| Typical Battery Recharge Time | 4 Hour |
| Controls/Indicators | |
| Status Indicators |
LED Status Display:
LED Status Indicators:
|
| Environmental Conditions | |
| Thermal Dissipation | 1109 BTU/h |
| Maximum Operating Temperature | 40°C |
| Maximum Operating Elevation | 2.01 km |
| Maximum Storage Elevation | 15.24 km |
| Sound Emission (A-Weighted) | 55 dB(A) |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Serial Port | Yes |
| EPO Port | Yes |
| USB (HID Compliant) Port | Yes |
| Management | |
| Alarm | Low Battery |
| Alarm | On Battery |
| Alarm | Overload |
| Physical Characteristics | |
| Weight (Approximate) | 51.90 kg |
| Form Factor | Tower/Rack Convertible |
| Height | 177.8 mm |
| Width | 439.9 mm |
| Depth | 620 mm |
| Power Description | |
| Output Voltage | 240 V AC |
| Output Voltage | 220 V AC |
| Output Voltage | 230 V AC |
| Waveform Type | Sine Wave |
| Input Voltage Range | 160 V AC - 285 V AC |
| Output Frequency | 60 Hz |
| Input Frequency | 70 Hz |
| Load Capacity (VA) | 5 kVA |
| Load Capacity (Watt) | 5 kW |
| Technical Information | |
| Application/Usage | Medical |
| Application/Usage | Voice/Data Network |
| Application/Usage | Server |
| Application/Usage | Light Industrial Application |
| Application/Usage | IT Equipment |
| Application/Usage | Business-critical System |
| Overload Protection | Yes |
| Receptacle Type | Hard wire 3-wire (H N + E) (Battery Backup) |
| Receptacle Type | IEC 60320 C13 |
| Receptacle Type | IEC 60320 C19 |
| Transfer Time | 0 ns |
| Receptacle Detail | 1 x Hard wire 3-wire (H N + E) (Battery Backup) |
| Receptacle Detail | 1 x IEC 60320 C19 |
| Receptacle Detail | 2 x IEC 60320 C13 |
