Controls/Indicators | |
---|---|
Status Indicators | Multifunction LCD |
Environmental Conditions | |
Maximum Operating Temperature | 40°C |
Maximum Operating Elevation | 3 km |
Maximum Storage Elevation | 14.76 km |
Operating Humidity | 0% - 95% |
Storage Relative Humidity | 0% - 95% |
Storage Temperature | -20°C - 50°C |
Interfaces/Ports | |
Serial Port | Yes |
USB (HID Compliant) Port | Yes |
Miscellaneous | |
Environmentally Friendly | Yes |
Physical Characteristics | |
Weight (Approximate) | 18.20 kg |
Form Factor | Rack-mountable |
Height | 86 mm |
Width | 437 mm |
Depth | 462 mm |
Power Description | |
Input Voltage | 230 V AC |
Output Voltage | 220 V AC |
Output Voltage | 230 V AC |
Output Voltage | 240 V AC |
Load Capacity | 2 kVA/1.60 kW |
Surge Energy Rating | 600 J |
Waveform Type | Sine Wave |
Input Voltage Range | 160 V AC - 280 V AC |
Output Frequency | 60 Hz |
Input Frequency | 70 Hz |
Technical Information | |
Application/Usage | Business |
Plug/Connector Type | IEC 60320 C14 |
Phase | Single Phase |
