Cisco
SKU:C9300X-48HX-A
Couldn't load pickup availability
Click to WhatsApp us to confirm stock availability
View full details
| I/O Expansions | |
|---|---|
| Expansion Slot Type | Uplink Module |
| Total Number of Expansion Slots | 1.0 |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Modular | Yes |
| Uplink Port | Yes |
| Stack Port | Yes |
| Total Number of Network Ports | 48 |
| Port/Expansion Slot Details | 48 x 10 Gigabit Ethernet UPoE+ |
| Port/Expansion Slot Details | 1 x Uplink |
| Management & Protocols | |
| Manageable | Yes |
| Media & Performance | |
| Network Technology | 10GBase-T |
| Ethernet Technology | 10 Gigabit Ethernet |
| Media Type Supported | Twisted Pair |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Network & Communication | |
| Layer Supported | 3 |
| Networking Standards | IEEE 802.1Q |
| Networking Standards | IEEE 802.1s |
| Networking Standards | IEEE 802.1w |
| Networking Standards | IEEE 802.1x |
| Networking Standards | IEEE 802.3 |
| Networking Standards | IEEE 802.3ab |
| Networking Standards | IEEE 802.3ad |
| Networking Standards | IEEE 802.3bz |
| Networking Standards | IEEE 802.3u |
| Networking Standards | IEEE 802.3af |
| Networking Standards | IEEE 802.3an |
| Networking Standards | IEEE 802.3at |
| Networking Standards | IEEE 802.3bt |
| Networking Standards | IEEE 802.3x |
| Networking Standards | IEEE 802.3z |
| Networking Standards | IEEE 802.1ae |
| Networking Standards | IEEE 802.1AVB |
| Networking Standards | IEEE 802.1br |
| Networking Standards | IEEE 802.1D |
| Networking Standards | IEEE 802.1p |
| Physical Characteristics | |
| Weight (Approximate) | 6.62 kg |
| Height | 43.9 mm |
| Width | 444.5 mm |
| Depth | 482.6 mm |
| Power Description | |
| Power Source | Power Supply |
| Frequency | 60 Hz |
| Frequency | 50 Hz |
| Number of Power Supplies Supported | 2 |
| Number of Power Supplies Installed | 1 |
| PoE (RJ-45) Port | Yes |
| Redundant Power Supply Supported | Yes |
