Chipset | |
---|---|
Chipset Manufacturer | Intel |
Display & Graphics | |
Graphics Controller Manufacturer | Intel |
Graphics Controller Model | UHD Graphics 770 |
Graphics Memory Technology | DDR5 SDRAM |
Graphics Memory Accessibility | Shared |
Interfaces/Ports | |
Total Number of USB Ports | 5 |
Number Of Ethernet Ports | 1 |
Number of DisplayPort Outputs (Rear) | 3 |
DisplayPort (Rear) | Yes |
Number of USB 3.2 Gen 1 Ports | 1 |
Number of USB 3.2 Gen 2 Ports | 3 |
Number of USB 3.2 Gen 2x2 Type-C Ports | 1 |
Optional Ports |
Details regarding optional ports aggregated from the information available for this product's family/series. Optional Modules
|
Memory | |
Maximum Memory Supported | 64 GB |
Standard Memory | 8 GB |
Memory Technology | DDR5 SDRAM |
Total Number of Memory Slots | 2.0 |
Miscellaneous | |
Package Contents |
|
Features | Security Slot |
Energy Star | Yes |
TCO Certified | Yes |
Network & Communication | |
Ethernet Technology | Gigabit Ethernet |
Physical Characteristics | |
Weight (Approximate) | 1.31 kg |
Form Factor | Micro PC |
Height | 182.1 mm |
Width | 36.1 mm |
Depth | 178.1 mm |
Processor | |
Processor Speed | 1.30 GHz |
Processor Type | Core i7 |
Processor Model | i7-14700T |
Processor Core | Icosa-core (20 Core) |
Processor Manufacturer | Intel |
vPro Technology | Yes |
Maximum Turbo Speed | 5.20 GHz |
Processor Generation | 14th Gen |
Processor Threads | 28 |
Storage | |
Drive Type | SSD |
Solid State Drive Interface | PCI Express NVMe 4.0 |
Total Solid State Drive Capacity | 512 GB |
SSD Form Factor | M.2 |
