Hewlett Packard Enterprise
SKU:JL807A
Couldn't load pickup availability
WhatsApp us to confirm stock availability before placing your order.
View full details
| I/O Expansions | |
|---|---|
| Expansion Slot Type | SFP+ |
| Number of SFP+ Slots | 2 |
| Total Number of Expansion Slots | 2.0 |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Modular | Yes |
| Uplink Port | Yes |
| Stack Port | Yes |
| Total Number of Network Ports | 26 |
| Port/Expansion Slot Details | 20 x Gigabit Ethernet PoE+ |
| Port/Expansion Slot Details | 4 x Gigabit Ethernet PoE++ |
| Port/Expansion Slot Details | 2 x 10 Gigabit Ethernet Expansion Slot |
| Port/Expansion Slot Details | 2 x 10 Gigabit Ethernet Network |
| Management & Protocols | |
| Manageable | Yes |
| Media & Performance | |
| Network Technology | 10GBase-T |
| Network Technology | 10/100/1000Base-T |
| Network Technology | 10GBase-X |
| Ethernet Technology | Gigabit Ethernet |
| Ethernet Technology | 10 Gigabit Ethernet |
| Media Type Supported | Optical Fiber |
| Media Type Supported | Twisted Pair |
| Network & Communication | |
| Layer Supported | 2 |
| Networking Standards | IEEE 802.1t |
| Networking Standards | IEEE 802.1w |
| Networking Standards | IEEE 802.1x |
| Networking Standards | IEEE 802.1s |
| Networking Standards | IEEE 802.1Q |
| Networking Standards | IEEE 802.1p |
| Networking Standards | IEEE 802.1D |
| Networking Standards | IEEE 802.3z |
| Networking Standards | IEEE 802.3x |
| Networking Standards | IEEE 802.3u |
| Networking Standards | IEEE 802.3i |
| Networking Standards | IEEE 802.3bt |
| Networking Standards | IEEE 802.3az |
| Networking Standards | IEEE 802.3at |
| Networking Standards | IEEE 802.3an |
| Networking Standards | IEEE 802.3af |
| Networking Standards | IEEE 802.3ae |
| Networking Standards | IEEE 802.3ad |
| Networking Standards | IEEE 802.3ac |
| Networking Standards | IEEE 802.3ab |
| Physical Characteristics | |
| Weight (Approximate) | 4.72 kg |
| Form Factor | Table Top |
| Form Factor | Cabinet Mount |
| Form Factor | Under Table |
| Form Factor | Rack-mountable |
| Form Factor | Wall Mountable |
| Height | 44 mm |
| Width | 442.5 mm |
| Depth | 350.5 mm |
| Power Description | |
| Power Source | Power Supply |
| Frequency | 50 Hz |
| Frequency | 60 Hz |
| Power Consumption | 80 W |
| Number of Power Supplies Installed | 1 |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 370 W |
| Warranty | |
| Additional Warranty Information | Limited Lifetime Warranty with 24x7 phone support for 90 days and chat support for the entire warranty duration. |
