Chipset |
Chipset Manufacturer |
Intel |
Chipset Model |
C621A |
Controllers |
Controller Type |
12Gb/s SAS |
RAID Supported |
Yes |
Controller Model |
Smart Array P408i-a |
Display & Graphics |
Graphics Memory Capacity |
16 MB |
I/O Expansions |
"Number of Internal 2.5"" Bays" |
8 |
Number of Total Expansion Bays |
8 |
Total Number of Expansion Slots |
3.0 |
Hot Swappable Bays |
Yes |
PCI Express x16 (Gen 3.x) Slots |
1 |
PCI Express x8 (Gen 3.x) Slots |
2 |
Number of SFF Bays |
8 |
PCI Express Details |
PCI-Express 4.0 Slots 3-slots (x8, x16, x8) as standard |
Interfaces/Ports |
VGA |
Yes |
Number of Network (RJ-45) Ports |
2 |
Network (RJ-45) |
Yes |
DisplayPort |
Yes |
Remote Management |
Yes |
Total Number of USB Ports |
5 |
Number of USB 3.0 Ports |
3 |
Number of VGA Ports |
1 |
Number of DisplayPorts |
1 |
Remote Management Controller |
HPE iLO Remote Management Network Port |
Memory |
Maximum Memory Supported |
2 TB |
Signal Processing |
Registered (Buffered) |
Standard Memory |
32 GB |
Memory Technology |
DDR4 SDRAM |
Number of Occupied Memory Slots |
1 |
Memory Clock Speed |
3.20 GHz |
Total Number of Memory Slots |
32.0 |
Miscellaneous |
Security Features |
- UEFI Secure Boot and Secure Start support
- Tamper-free updates - components digitally signed and verified
- Immutable Silicon Root of Trust
- Ability to rollback firmware
- FIPS 140-2 validation
- Secure erase of NAND/User data
- Common Criteria certification
- TPM (Trusted Platform Module) 1.2 option
- Configurable for PCI DSS compliance
- TPM (Trusted Platform Module) 2.0 option
- Advanced Encryption Standard (AES) and Triple Data Encryption Standard (3DES) on browser
- Bezel Locking Kit option
- Support for Commercial National Security Algorithms (CNSA)
- Chassis Intrusion detection option
- Secure Recovery - recover critical firmware to known good state on detection of compromised firmware
|
Network & Communication |
Ethernet Technology |
10 Gigabit Ethernet |
Operating System |
Operating System |
No |
Operating System Supported |
Windows Server 2019 |
Operating System Supported |
Windows Server 2016 |
Operating System Supported |
Ubuntu 20.04 LTS |
Operating System Supported |
Red Hat Enterprise Linux 8.2 |
Operating System Supported |
SUSE Linux Enterprise Server 12 SP5 |
Operating System Supported |
SUSE Linux Enterprise Server 15 SP2 |
Operating System Supported |
Red Hat Enterprise Linux 7.9 |
Physical Characteristics |
Weight (Approximate) |
28.77 kg |
Form Factor |
Rack |
Rack Height |
2U |
Height |
87.5 mm |
Width |
445.4 mm |
Depth |
710 mm |
Power Description |
Plug/Connector Type |
C13/C14 |
Number of Power Supplies Supported |
2 |
Number of Power Supplies Installed |
1 |
Hot Swappable Power Supply |
Yes |
Maximum Power Supply Wattage |
800 W |
Processor |
Cache |
24 MB |
Processor Speed |
2.40 GHz |
Processor Type |
Xeon Silver |
Processor Model |
4314 |
Processor Core |
Hexadeca-core (16 Core) |
Processor Manufacturer |
Intel |
Number of Processors Supported |
2 |
Number of Processors Installed |
1 |
Processor Generation |
3rd Gen |
Storage |
Optical Drive Type |
No |
Number of Hard Drives |
No |
Warranty |
Additional Warranty Information |
3/3/3 - Server Warranty includes three years of parts, three years of labor, three years of onsite support coverage with NBD response |
