Chipset | |
---|---|
Chipset Manufacturer | Intel |
Chipset Model | W680 |
Controllers | |
RAID Levels | 0, 1 |
Controller Type | NVMe |
RAID Supported | Yes |
Display & Graphics | |
Graphics Controller Manufacturer | NVIDIA |
Graphics Controller Model | T1000 |
Graphics Memory Capacity | 8 GB |
Graphics Memory Accessibility | Dedicated |
Maximum Memory Bandwidth | 160 GB/s |
Interfaces/Ports | |
DisplayPort | Yes |
Number of DisplayPort Outputs | 2 |
Total Number of USB Ports | 6 |
Mini DisplayPort | Yes |
Number Of Ethernet Ports | 1 |
USB Type-C | Yes |
USB Type-C Detail | 2 SuperSpeed USB Type-C® 20Gbps signaling rate |
Number of Mini DisplayPort | 4 |
Memory | |
Error Checking | Non-ECC |
Maximum Memory Supported | 64 GB |
Standard Memory | 32 GB |
Memory Technology | DDR5 SDRAM |
Memory Clock Speed | 5.60 GHz |
Memory Configuration | 2 x 16 GB |
Total Number of Memory Slots | 2 |
Miscellaneous | |
Package Contents |
|
Environmentally Friendly | Yes |
Environmental Certification | China Environmental United Certification Center (CEC) |
Energy Star | Yes |
TCO Certified | Yes |
Energy Efficiency Certification | China Energy Conservation Program (CECP) |
Energy Efficiency Compliance | Energy-related Products Directive (ErP) |
Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
Network & Communication | |
Bluetooth | Yes |
Wireless LAN | Yes |
Ethernet Technology | 10 Gigabit Ethernet |
Operating System | |
Operating System | Windows 11 Pro |
Operating System Platform | Windows |
Physical Characteristics | |
Weight (Approximate) | 2.40 kg |
Form Factor | Mini PC |
Cooler Type | Air Cooler |
Height | 69 mm |
Width | 211 mm |
Depth | 218 mm |
Power Description | |
Input Voltage | 230 V AC |
Input Voltage | 120 V AC |
Maximum Power Supply Wattage | 280 W |
Processor | |
Processor Speed | 2.10 GHz |
Processor Type | Core i7 |
Processor Socket | Socket LGA-1700 |
Processor Model | i7-13700 |
Processor Core | Hexadeca-core (16 Core) |
Processor Manufacturer | Intel |
Number of Processors Supported | 1 |
Number of Processors Installed | 1 |
vPro Technology | Yes |
Processor Generation | 13th Gen |
Processor Threads | 24 |
Storage | |
Drive Type | SSD |
Solid State Drive Interface | PCI Express NVMe |
Total Solid State Drive Capacity | 512 GB |
Warranty | |
Additional Warranty Information | HP Care Helpdesk per Device SVC, 3 Year. |
