Built-in Devices |
Webcam |
Yes |
Camera Privacy Shutter |
Yes |
Chipset |
Chipset Manufacturer |
Intel |
Chipset Model |
Q670 |
Display & Graphics |
Screen Resolution |
1920 x 1080 |
Brightness |
250 cd/m² |
Screen Size |
60.5 cm (23.8") |
Screen Mode |
Full HD |
Touchscreen |
Yes |
Standard Refresh Rate |
60 Hz |
Graphics Controller Manufacturer |
Intel |
Graphics Controller Model |
UHD Graphics 770 |
Graphics Memory Technology |
DDR5 SDRAM |
Graphics Memory Accessibility |
Shared |
Input Devices |
Keyboard Localization |
English |
Interfaces/Ports |
Total Number of USB Ports |
7 |
Number Of Ethernet Ports |
1 |
USB Type-C Detail |
1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with data transfer and 15W charging |
HDMI (Rear) |
Yes |
USB Type-C (Rear) |
Yes |
Number of DisplayPort Outputs (Rear) |
1 |
DisplayPort (Rear) |
Yes |
Number of USB 3.2 Gen 1 Ports |
3 |
Number of USB 3.2 Gen 2 Ports |
3 |
Memory |
Maximum Memory Supported |
64 GB |
Standard Memory |
16 GB |
Memory Technology |
DDR5 SDRAM |
Number of Occupied Memory Slots |
1 |
Memory Configuration |
1 x 16GB |
Total Number of Memory Slots |
2.0 |
Miscellaneous |
Package Contents |
ThinkCentre M90a Gen 5 12SH001QSG
Keyboard
Mouse
UltraFlex V Stand
VESA Mount
|
Features |
Flicker-free |
Features |
Low Blue Light |
Features |
Security Slot |
Features |
Dust Resistant |
Environmentally Friendly |
Yes |
Environmental Certification |
TCO Certified 9.0 |
Environmental Certification |
TCO Certified Edge |
Environmental Certification |
GREENGUARD |
Environmental Certification |
Electronic Product Environmental Assessment Tool Gold (EPEAT Gold) |
Energy Star |
Yes |
TCO Certified |
Yes |
Energy Efficiency Certification |
ENERGY STAR 8.0 |
Energy Efficiency Compliance |
Energy-related Products Directive Lot 3 (ErP Lot 3) |
Environmental Compliance |
Restriction of Hazardous Substances (RoHS) |
Network & Communication |
Bluetooth |
Yes |
Wireless LAN |
Yes |
Wireless LAN Standard |
IEEE 802.11ax |
Ethernet Technology |
Gigabit Ethernet |
Operating System |
Operating System |
Windows 11 Pro |
Operating System Platform |
Windows |
Operating System Language |
English |
Physical Characteristics |
Weight (Approximate) |
7.83 kg |
Form Factor |
Desktop |
Height |
472 mm |
Width |
539.6 mm |
Depth |
252.6 mm |
Product Color |
Black |
Color Family |
Black |
Power Description |
Maximum Power Supply Wattage |
180 W |
Processor |
Processor Speed |
2.10 GHz |
Processor Type |
Core i7 |
Processor Model |
i7-13700 |
Processor Core |
Hexadeca-core (16 Core) |
Processor Manufacturer |
Intel |
vPro Technology |
Yes |
Maximum Turbo Speed |
5.10 GHz |
Processor Generation |
13th Gen |
Processor Threads |
24 |
Storage |
Drive Type |
SSD |
Solid State Drive Interface |
PCI Express NVMe 4.0 x4 |
Total Solid State Drive Capacity |
512 GB |
SSD Form Factor |
M.2 |
Technical Information |
Release Year |
2024 |
Warranty |
Additional Warranty Information |
- Base Warranty 1-year, Onsite
- Included Upgrade 3Y Onsite upgrade from 1Y Onsite
|
