Ruckus
SKU:ICX8200-48
Couldn't load pickup availability
WhatsApp us to confirm stock availability before placing your order.
View full details
| I/O Expansions | |
|---|---|
| Expansion Slot Type | SFP28 |
| Total Number of Expansion Slots | 4 |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Uplink Port | Yes |
| Stack Port | Yes |
| Total Number of Network Ports | 48 |
| Port/Expansion Slot Details | 48 x Gigabit Ethernet Network |
| Port/Expansion Slot Details | 4 × 25 Gigabit Ethernet SFP28 Stacking/ Uplink-Ports |
| Management & Protocols | |
| Manageable | Yes |
| Data Link Protocols | HTTPS |
| Data Link Protocols | HTTP |
| Media & Performance | |
| Network Technology | 10/100/1000Base-T |
| Network Technology | 25GBase-X |
| Ethernet Technology | 25 Gigabit Ethernet |
| Ethernet Technology | Gigabit Ethernet |
| Media Type Supported | Twisted Pair |
| Media Type Supported | Optical Fiber |
| Miscellaneous | |
| Application/Usage | Industrial |
| Application/Usage | Network |
| Application/Usage | Office |
| Application/Usage | Security |
| Application/Usage | Server |
| Application/Usage | Business |
| Application/Usage | Campus |
| Application/Usage | Enterprise |
| Network & Communication | |
| Layer Supported | 3 |
| Networking Standards | IEEE 802.1AX |
| Networking Standards | IEEE 802.1br |
| Networking Standards | IEEE 802.1D |
| Networking Standards | IEEE 802.1p |
| Networking Standards | IEEE 802.1Q |
| Networking Standards | IEEE 802.1s |
| Networking Standards | IEEE 802.1w |
| Networking Standards | IEEE 802.1x |
| Networking Standards | IEEE 802.3 |
| Networking Standards | IEEE 802.3ab |
| Networking Standards | IEEE 802.3ad |
| Networking Standards | IEEE 802.3ae |
| Networking Standards | IEEE 802.3at |
| Networking Standards | IEEE 802.3az |
| Networking Standards | IEEE 802.3bt |
| Networking Standards | IEEE 802.3bz |
| Networking Standards | IEEE 802.3u |
| Networking Standards | IEEE 802.3x |
| Networking Standards | IEEE 802.3z |
| Networking Standards | IEEE802.3af |
| Networking Standards | IEEE 802.1ab |
| Physical Characteristics | |
| Weight (Approximate) | 4.96 kg |
| Form Factor | DIN Rail Mountable |
| Form Factor | Rack-mountable |
| Form Factor | Wall Mountable |
| Height | 44 mm |
| Width | 440 mm |
| Depth | 370 mm |
| Power Description | |
| Input Voltage | 120 V AC |
| Input Voltage | 230 V AC |
| Power Source | AC |
| Power Source | Power Supply |
| Frequency | 50 Hz |
| Frequency | 60 Hz |
| Power Consumption | 47 W |
| Plug/Connector Type | C14 |
| Reliability | |
| MTBF | 1136723 Hour |
| Technical Information | |
| Features | DHCP Snooping |
| Features | Energy Efficient |
| Features | Fanless |
| Features | Hot-swappable |
| Features | In-Service Software Upgrade (ISSU) |
| Features | Access Control List |
