Vertiv
SKU:CP8953
Couldn't load pickup availability
Click to WhatsApp us to confirm stock availability
View full details
| Interfaces/Ports | |
|---|---|
| Network (RJ-45) | Yes |
| Management | |
| Management |
|
| Remote Outlet Switching | Yes |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Compliance | China Restriction of Hazardous Substances (China RoHS) |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Physical Characteristics | |
| Mount Type | Rack-mountable |
| Rack Height | 0U |
| Height | 1683 mm |
| Width | 51 mm |
| Depth | 66 mm |
| Mounting Orientation | Vertical/Toolless |
| Product Color | Black Powder Coat |
| Color Family | Black |
| Power Description | |
| Input Voltage | 230 V AC |
| Output Voltage | 230 V AC |
| Input Current | 32 A |
| Power Rating (Watt) | 7.30 kW |
| Technical Information | |
| Protection Type | Single Pole |
| Protection Type | Overcurrent Protection |
| Protection Type | Circuit Breaker |
| Plug/Connector Type | IEC 60309 (2P+E) 32A |
| Receptacle Type | U-Lock IEC 60320 C13 |
| Receptacle Type | U-Lock IEC 60320 C19 |
| PDU Type | Switched |
| Locking Receptacles | IEC 60320 C13 |
| Locking Receptacles | IEC 60320 C19 |
| Receptacle Detail | 20 x U-Lock IEC 60320 C13 |
| Receptacle Detail | 4 x U-Lock IEC 60320 C19 |
| Plug/Connector Detail | 1 x IEC 60309 (2P+E) 32A |
| Warranty | |
| Additional Warranty Information | 5-year limited warranty if registered within 120 days of purchase, otherwise warranty defaults to 3 years |
