EDGE UPS UPS 3kVA 230V 2U Rack/Tower - Vertiv
Battery Information |
Battery Chemistry |
Lead Acid |
Hot Swappable |
Yes |
Battery Size |
12V |
Battery Capacity |
10000 mAh |
Number of Batteries |
6 |
Backup/Run Time (Half Load) |
16 Minute |
Backup/Run Time (Full Load) |
6 Minute |
Battery Characteristics |
Valve-regulated, Non-spillable |
DC System Voltage |
72 V DC |
Typical Battery Recharge Time |
4 Hour |
Number of External Battery Cabinets |
6 |
Controls/Indicators |
Status Indicators |
Color and graphic LCD |
Environmental Conditions |
Sound Emission |
45 dB |
Maximum Operating Temperature |
40°C |
Maximum Operating Elevation |
3 km |
Interfaces/Ports |
USB |
Yes |
VGA |
No |
Modem (RJ-11) |
No |
Serial Port |
No |
EPO Port |
Yes |
USB (HID Compliant) Port |
Yes |
Management |
Network Management |
SNMP/Webcard |
Miscellaneous |
Software Included |
Power Assist |
Country of Origin |
China |
Environmentally Friendly |
Yes |
TAA Compliant |
No |
Energy Star |
No |
Environmental Compliance |
Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
Environmental Compliance |
Restriction of Hazardous Substances (RoHS) |
Physical Characteristics |
Weight (Approximate) |
32 kg |
Form Factor |
Rack/Tower |
Rack Height |
2U |
Height |
88 mm |
Width |
438 mm |
Depth |
630 mm |
Product Color |
Black |
Color Family |
Black |
Power Description |
Input Voltage |
278 V |
Output Voltage |
220 V AC |
Output Voltage |
230 V AC |
Output Voltage |
240 V AC |
Output Voltage |
208 V AC |
Output Voltage |
200 V AC |
Surge Energy Rating |
624 J |
Waveform Type |
Pure Sine Wave |
Input Frequency |
65 Hz |
Load Capacity (VA) |
3 kVA |
Technical Information |
Application/Usage |
Business |
Application/Usage |
Critical System |
Application/Usage |
Data Center |
Application/Usage |
Data Storage |
Application/Usage |
Edge Computing |
Application/Usage |
IOT Device |
Application/Usage |
Network |
Application/Usage |
Server |
Plug/Connector Type |
IEC 60320 C20 |
Phase |
Single Phase |
Receptacle Type |
IEC 60320 C13 |
Receptacle Type |
IEC 60320 C19 |
AVR |
Yes |
Transfer Time |
6 ms |
Receptacle Detail |
6 x IEC 60320 C13 |
Receptacle Detail |
1 x IEC 60320 C19 |
