Vertiv
SKU:EDGE-500IRM1U
Couldn't load pickup availability
Click to WhatsApp us to confirm stock availability
View full details
| Battery Information | |
|---|---|
| Battery Life | 5 Year |
| Battery Chemistry | Lead Acid |
| Hot Swappable | Yes |
| Battery Size | 6V |
| Battery Capacity | 9000 mAh |
| Number of Batteries | 2 |
| Backup/Run Time (Half Load) | 15 Minute |
| Backup/Run Time (Full Load) | 5 Minute |
| Battery Characteristics | Valve-regulated, Non-spillable |
| DC System Voltage | 72 V DC |
| Typical Battery Recharge Time | 3 Hour |
| Number of External Battery Cabinets | 6 |
| Controls/Indicators | |
| Status Indicators | Color and graphic LCD |
| Environmental Conditions | |
| Sound Emission | 45 dB |
| Maximum Operating Temperature | 40°C |
| Maximum Operating Elevation | 3 km |
| Interfaces/Ports | |
| USB | Yes |
| VGA | No |
| Network (RJ-45) | No |
| Modem (RJ-11) | Yes |
| Serial Port | No |
| EPO Port | Yes |
| USB (HID Compliant) Port | Yes |
| Management | |
| Network Management | SNMP/Webcard |
| Alarm | Yes |
| Miscellaneous | |
| Software Included | Power Assist |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| TAA Compliant | No |
| Energy Star | No |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Physical Characteristics | |
| Weight (Approximate) | 11 kg |
| Form Factor | Rack-mountable |
| Rack Height | 1U |
| Height | 44 mm |
| Width | 438 mm |
| Depth | 380 mm |
| Product Color | Black |
| Color Family | Black |
| Power Description | |
| Circuit Breaker | Yes |
| Input Voltage | 278 V |
| Output Voltage | 200 V AC |
| Output Voltage | 220 V AC |
| Output Voltage | 240 V AC |
| Output Voltage | 230 V AC |
| Output Voltage | 208 V AC |
| Surge Energy Rating | 624 J |
| Waveform Type | Pure Sine Wave |
| Input Frequency | 65 Hz |
| Load Capacity (VA) | 500 VA |
| Technical Information | |
| Application/Usage | Server |
| Application/Usage | Network |
| Application/Usage | Business |
| Application/Usage | Edge Computing |
| Application/Usage | IOT Device |
| Application/Usage | Critical System |
| Application/Usage | Data Center |
| Application/Usage | Data Storage |
| Plug/Connector Type | IEC 60320 C14 |
| Cord Length | 3 m |
| Phase | Single Phase |
| Receptacle Type | IEC 60320 C13 |
| AVR | Yes |
| Transfer Time | 6 ms |
| Receptacle Detail | 6 x IEC 60320 C13 |
