Vertiv
SKU:EDGELI-2200IRT2U
Couldn't load pickup availability
Click to WhatsApp us to confirm stock availability
View full details
| Battery Information | |
|---|---|
| Battery Life | 5 Year |
| Battery Chemistry | Lithium Ion (Li-Ion) |
| Hot Swappable | Yes |
| Battery Capacity | 2500 mAh |
| Number of Batteries | 2 |
| Backup/Run Time (Half Load) | 20.20 Minute |
| Backup/Run Time (Full Load) | 9.30 Minute |
| Backup/Run Time (With Optional Battery) | No |
| DC System Voltage | 72 V DC |
| Typical Battery Recharge Time | 1.70 Hour |
| Controls/Indicators | |
| Status Indicators |
|
| Environmental Conditions | |
| Thermal Dissipation | 101.40 BTU/h |
| Maximum Operating Temperature | 40°C |
| Maximum Operating Elevation | 3 km |
| Sound Emission (A-Weighted) | 45 dB(A) |
| Interfaces/Ports | |
| USB | Yes |
| VGA | No |
| Network (RJ-45) | No |
| Modem (RJ-11) | No |
| Serial Port | No |
| Total Number of Expansion Slots | 1 |
| USB (HID Compliant) Port | Yes |
| Management | |
| Alarm | Yes |
| Miscellaneous | |
| Additional Information |
|
| Package Contents |
|
| Software Included | Vertiv Power Assist, Vertiv Power Insight |
| Certifications & Standards |
|
| Country of Origin | China |
| Environmentally Friendly | Yes |
| TAA Compliant | No |
| Energy Star | No |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) 2 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Physical Characteristics | |
| Weight (Approximate) | 17.50 kg |
| Form Factor | Rack/Tower |
| Rack Height | 2U |
| Height | 86 mm |
| Width | 438 mm |
| Depth | 510 mm |
| Product Color | Black |
| Color Family | Black |
| Power Description | |
| Circuit Breaker | Yes |
| Input Voltage | 230 V AC |
| Output Voltage | 200 V AC |
| Output Voltage | 208 V AC |
| Output Voltage | 220 V AC |
| Output Voltage | 240 V AC |
| Output Voltage | 230 V AC |
| Input Current | 15.30 A |
| Power Consumption | 20 W |
| Surge Energy Rating | 624 J |
| Waveform Type | Sinusoidal |
| Input Voltage Range | 166 V AC - 278 V AC |
| Input Frequency | 65 Hz |
| Load Capacity (VA) | 2.20 kVA |
| Extra Power for Future Expansion | No |
| Technical Information | |
| Application/Usage | IT Equipment |
| Application/Usage | Network Closet |
| Application/Usage | Business-critical System |
| Application/Usage | Server Room |
| Bypass Switch | No |
| Dataline Protection | No |
| Emergency Power OFF | Yes |
| Protection Type | Under Voltage |
| Protection Type | Input Breaker |
| Protection Type | Over Voltage |
| Protection Type | Sag |
| Protection Type | Spike |
| Protection Type | Surge |
| Protection Type | Transient |
| Plug/Connector Type | IEC 60320 C20 |
| Phase | Single Phase |
| Receptacle Type | IEC 60320 C13 |
| Receptacle Type | IEC 60320 C10 |
| EMI/RFI Noise Filter | Yes |
| AVR | Yes |
| Transfer Time | 6 ms |
| Receptacle Detail | 1 x IEC 60320 C10 |
| Receptacle Detail | 6 x IEC 60320 C13 |
