Vertiv
SKU:EXS 0030KTH16FN01000
Couldn't load pickup availability
Click to WhatsApp us to confirm stock availability
View full details
| Battery Information | |
|---|---|
| Battery Chemistry | Lead Acid |
| Battery Chemistry | Lithium Ion (Li-Ion) |
| Battery Characteristics | Valve-regulated |
| Display & Graphics | |
| Display | LCD |
| Environmental Conditions | |
| Maximum Operating Temperature | 40°C |
| Interfaces/Ports | |
| USB (HID Compliant) Port | Yes |
| Management | |
| Network Management | SNMP/Modbus |
| Physical Characteristics | |
| Weight (Approximate) | 600 kg |
| Form Factor | Tower |
| Height | 1600 mm |
| Width | 440 mm |
| Depth | 750 mm |
| Power Description | |
| Input Voltage | 415 V AC |
| Input Voltage | 380 V AC |
| Input Voltage | 400 V AC |
| Output Voltage | 415 V AC |
| Output Voltage | 380 V AC |
| Output Voltage | 400 V AC |
| Input Voltage Range | 228 V AC - 475 V AC |
| Output Frequency | 60 Hz |
| Input Frequency | 70 Hz |
| Load Capacity (VA) | 30 kVA |
| Load Capacity (Watt) | 30 kW |
| Input Power Factor | 0.99 |
| Output Power Factor | 1 |
| Technical Information | |
| Application/Usage | Network |
| Application/Usage | IT Infrastructure |
| Application/Usage | Industrial |
| Application/Usage | Healthcare |
| Application/Usage | Government Facilities |
| Application/Usage | Emergency Lighting |
| Application/Usage | Data Center |
| Application/Usage | Transportation |
| Application/Usage | Retail |
| Application/Usage | Mission Critical Equipment |
| Application/Usage | Commercial |
| Application/Usage | Central Power Supply System (CPSS) |
| Plug/Connector Type | 3PH + N + PE |
| Phase | Three Phase |
| Receptacle Type | 3PH + N + PE |
