Battery Information | |
---|---|
Battery Life | 5 Year |
Battery Chemistry | Lead Acid |
Hot Swappable | Yes |
Battery Size | 12V |
Hot Pluggable | Yes |
Number of Batteries | 3 |
Backup/Run Time (Half Load) | 9 Minute |
Backup/Run Time (Full Load) | 3 Minute |
Battery Characteristics | Valve-regulated, Non-spillable |
Typical Battery Recharge Time | 3 Hour |
Number of External Battery Cabinets | 1 |
Backup/Run Time With External Battery Cabinet (Full Load) | 17 Minute |
Backup/Run Time With External Battery Cabinet (Half Load) | 42 Minute |
Controls/Indicators | |
Status Indicators | Color LCD |
Environmental Conditions | |
Maximum Operating Temperature | 40°C |
Maximum Operating Elevation | 3 km |
Maximum Storage Elevation | 15 km |
Environmental Sensors | Leak Detection Sensor |
Environmental Sensors | Humidity Sensor |
Environmental Sensors | Temperature Sensor |
Interfaces/Ports | |
VGA | No |
Modem (RJ-11) | No |
Serial Port | Yes |
EPO Port | Yes |
USB (HID Compliant) Port | Yes |
Miscellaneous | |
Additional Information |
|
Assembly Required | No |
TAA Compliant | No |
Energy Star | Yes |
Physical Characteristics | |
Weight (Approximate) | 21.55 kg |
Form Factor | Rack/Tower |
Rack Height | 2U |
Height | 86.4 mm |
Width | 429.3 mm |
Depth | 469.9 mm |
Product Color | Black |
Color Family | Black |
Power Description | |
Circuit Breaker | Yes |
Output Voltage | 120 V AC |
Input Current | 16 A |
Waveform Type | Pure Sine Wave |
Output Current | 16.70 A |
Input Voltage Range | 60 V AC - 150 V AC |
Input Frequency | 70 Hz |
Load Capacity (VA) | 2 kVA |
User Selectable Output | Typical 120V User Selectable Output: 110/115/120VAC (user-configurable); ±3% |
Utility (AC) Mode Overload |
|
Technical Information | |
Application/Usage | IT Equipment |
Application/Usage | Mission Critical Equipment |
Emergency Power OFF | Yes |
Cord Length | 3.05 m |
Phase | Single Phase |
Receptacle Type | NEMA L5-20R |
Receptacle Type | NEMA 5-15/20R |
Transfer Time | 0 ns |
Receptacle Detail | 1 x NEMA L5-20R |
Receptacle Detail | 6 x NEMA 5-15/20R |
