Vertiv
SKU:GXT5-5000MVRT4UXLN
Couldn't load pickup availability
WhatsApp us to confirm stock availability before placing your order.
View full details
| Battery Information | |
|---|---|
| Battery Chemistry | Lead Acid |
| Hot Swappable | Yes |
| Backup/Run Time (Half Load) | 12.50 Minute |
| Backup/Run Time (Full Load) | 4.50 Minute |
| Battery Characteristics | Valve-regulated, Non-spillable, Flame-retardant |
| Replaceable Battery | Yes |
| Number of External Battery Cabinets | 1 |
| Backup/Run Time With External Battery Cabinet (Full Load) | 12.50 Minute |
| Backup/Run Time With External Battery Cabinet (Half Load) | 33 Minute |
| Controls/Indicators | |
| Status Indicators | LED/Full Color Graphic LCD |
| Environmental Conditions | |
| Maximum Operating Temperature | 40°C |
| Maximum Operating Elevation | 3 km |
| Environmental Sensors | Leak Detection Sensor |
| Environmental Sensors | Humidity Sensor |
| Environmental Sensors | Temperature Sensor |
| Interfaces/Ports | |
| USB | Yes |
| VGA | No |
| Network (RJ-45) | Yes |
| Modem (RJ-11) | No |
| Serial Port | Yes |
| Total Number of Expansion Slots | 1 |
| Miscellaneous | |
| Additional Information |
|
| TAA Compliant | No |
| Energy Star | Yes |
| Physical Characteristics | |
| Weight (Approximate) | 56.97 kg |
| Form Factor | Rack/Tower |
| Rack Height | 4U |
| Height | 172.7 mm |
| Width | 429.3 mm |
| Depth | 650.2 mm |
| Power Description | |
| Output Voltage | 120 V AC |
| Output Voltage | 208 V AC |
| Waveform Type | Pure Sine Wave |
| Input Frequency | 60 Hz |
| Load Capacity (VA) | 5 kVA |
| Load Capacity (Watt) | 5 kW |
| User Selectable Output | 208/120VAC |
| Utility (AC) Mode Overload |
|
| Technical Information | |
| Application/Usage | Data Center |
| Application/Usage | IT System |
| Application/Usage | Mission Critical Equipment |
| Bypass Switch | Internal |
| Bypass Switch | Maintenance |
| Bypass Switch | Automatic & Manual |
| Emergency Power OFF | Yes |
| Phase | Single Phase |
| Receptacle Type | Hardwired |
| Transfer Time | 0 ns |
