Zebra
SKU:DS2208-SR7U2100AZW
Couldn't load pickup availability
Click to WhatsApp us to confirm stock availability
View full details
| Interfaces/Ports | |
|---|---|
| Host Interface | Keyboard Wedge |
| Host Interface | USB |
| Host Interface | Serial |
| Miscellaneous | |
| Application/Usage | Hospitality |
| Application/Usage | Industrial |
| Application/Usage | Light/Clean Manufacturing |
| Application/Usage | Logistics |
| Application/Usage | Government |
| Application/Usage | Transportation |
| Application/Usage | Retail |
| Environmentally Friendly | Yes |
| Ingress Protection (IP) Rating | IP52 |
| Physical Characteristics | |
| Weight (Approximate) | 161.6 g |
| Form Factor | Handheld |
| Height | 165.1 mm |
| Width | 66 mm |
| Depth | 99.1 mm |
| Product Color | Twilight Black |
| Color Family | Black |
| Power Description | |
| Input Voltage | 5.5 V DC |
| Power Source | DC |
| Technical Information | |
| Barcode Symbology Supported |
1D:
|
| Connectivity Technology | Cable |
| Scanning Distance | 368.30 mm |
| Scanner Range | Standard Range |
| Drop Specification | Designed to withstand multiple drops at 5.0 ft./1.5 m to concrete |
| Scan Pattern | Omni-directional |
| Scan Rate | 30 scan/s |
| Image Sensor Type | Imager |
| Cable Type Included | USB |
| Scanning Capability | 1D |
| Scanning Capability | 2D |
| Field of View (Horizontal) | 33° |
| Field of View (Vertical) | 25° |
| Reading Angle (Skew) | 65° |
| Reading Angle (Pitch) | 65° |
| Reading Angle (Roll) | 360° |
| Motion Tolerance | 127 mm/s |
| Maximum Ambient Light | 107600 lux |
| Minimum Print Contrast | 25% |
| Maximum Element Resolution (Code 39) | 0.13 mm |
| Maximum Element Resolution (DataMatrix) | 0.25 mm |
| Maximum Element Resolution (PDF417) | 0.17 mm |
