DS4608-SR BLACK WITH STAND USB KIT DS460 - Zebra
|
|
| Interfaces/Ports |
|---|
| Host Interface |
Multi-interface |
|
|
| Miscellaneous |
|---|
| Application/Usage |
Industrial |
| Application/Usage |
Hospitality |
| Application/Usage |
Inventory |
| Application/Usage |
Retail |
| Ingress Protection (IP) Rating |
IP52 |
|
|
| Physical Characteristics |
|---|
| Weight (Approximate) |
161.9 g |
| Form Factor |
Handheld |
| Height |
165.1 mm |
| Width |
66 mm |
| Depth |
99.1 mm |
| Product Color |
Twilight Black |
|
|
| Technical Information |
|---|
| Barcode Symbology Supported |
1D:
- Code 39
- Code 128
- Code 93
- Codabar/NW7
- Code 11
- MSI Plessey
- UPC/EAN
- I 2 of 5
- Korean 3 of 5
- GS1 DataBar
- Base 32 (Italian Pharma)
2D:
- PDF417
- Micro PDF417
- Composite Codes
- TLC-39
- Aztec
- DataMatrix
- MaxiCode
- QR Code
- Micro QR
- Han Xin
- Postal Codes
- SecurPharm
- DotCode
- Dotted DataMatrix
OCR:
- OCR-A
- OCR-B
- MICR
- US Currency
|
| Connectivity Technology |
Cable |
| Scanning Distance |
710 mm |
| Scanner Range |
Standard Range |
| Drop Specification |
Designed to withstand multiple drops at 6.0 ft./1.8 m to concrete |
| Image Sensor Type |
Imager |
| Stand Included |
Yes |
| Cable Type Included |
USB |
| Scanning Capability |
1D |
| Scanning Capability |
2D |
| Field of View (Horizontal) |
36° |
| Field of View (Vertical) |
23° |
| Reading Angle (Skew) |
60° |
| Reading Angle (Pitch) |
60° |
| Reading Angle (Roll) |
360° |
| Maximum Ambient Light |
107000 lux |
| Minimum Print Contrast |
15% |
| Minimum Element Resolution (Code 39) |
0.08 mm |
| Maximum Element Resolution (Code 39) |
0.51 mm |
| Maximum Element Resolution (DataMatrix) |
0.25 mm |
| Maximum Element Resolution (PDF417) |
0.17 mm |
