Display & Graphics |
Display Screen |
Yes |
Display Screen Type |
LCD |
Fonts & Emulation |
Language Emulation |
ZBI |
Language Emulation |
ZPL II |
Language Emulation |
ZPL |
Interfaces/Ports |
USB |
Yes |
Serial Port |
Yes |
Parallel Port |
Yes |
Media Types & Handling |
Media Thickness |
304.8 µm |
Maximum Roll Diameter |
127 mm |
Media Type |
Tag Stock |
Media Type |
Direct Thermal Label |
Media Type |
Fanfold |
Media Type |
RFID Label |
Media Type |
Roll Fed |
Media Type |
Continuous Receipt |
Media Type |
Wristband |
Media Type |
Die-cut Label |
Media Sensor |
Reflective Media Sensor |
Media Sensor |
Transmissive Media Sensor |
Media Sensor |
Cover Open Sensor |
Ribbon Core Size |
12.70 mm |
Maximum Label Width |
107.95 mm |
Maximum Label Length |
990.60 mm |
Memory |
Flash Memory |
256 MB |
Standard Memory |
128 MB |
Memory Technology |
SDRAM |
Miscellaneous |
Platform Supported |
PC |
Certifications & Standards |
- FCC Part 15
- VCCI
- C-Tick
- CE
- CCC
- CCX
- IEC
- TUV
- NRTL
- Unicode
|
Environmentally Friendly |
Yes |
Energy Star |
Yes |
Network & Communication |
Ethernet |
Yes |
Ethernet Technology |
Fast Ethernet |
RFID |
Yes |
Physical Characteristics |
Weight (Approximate) |
2.22 kg |
Height |
190.5 mm |
Width |
193 mm |
Depth |
254 mm |
Power Description |
Input Voltage |
220 V AC |
Input Voltage |
110 V AC |
Power Source |
AC Supply |
Technical Information |
Application/Usage |
Desktop |
Barcode Symbology Supported |
Aztec Code |
Barcode Symbology Supported |
Codabar |
Barcode Symbology Supported |
Codablock |
Barcode Symbology Supported |
Code 11 |
Barcode Symbology Supported |
Code 128 |
Barcode Symbology Supported |
Code 39 |
Barcode Symbology Supported |
Code 49 |
Barcode Symbology Supported |
Code 93 |
Barcode Symbology Supported |
Data Matrix |
Barcode Symbology Supported |
Industrial 2 of 5 |
Barcode Symbology Supported |
Interleaved 2 of 5 |
Barcode Symbology Supported |
LOGMARS |
Barcode Symbology Supported |
Maxi Code |
Barcode Symbology Supported |
Micro PDF-417 |
Barcode Symbology Supported |
MSI |
Barcode Symbology Supported |
PDF-417 |
Barcode Symbology Supported |
Plessey |
Barcode Symbology Supported |
POSTNET |
Barcode Symbology Supported |
QR Code |
Barcode Symbology Supported |
Standard 2 of 5 |
Barcode Symbology Supported |
UPC-A |
Barcode Symbology Supported |
UPC-A with EAN 2 or 5 Digit Extension |
Barcode Symbology Supported |
UPC-E |
Barcode Symbology Supported |
UPC-E with EAN 2 or 5 Digit Extension |
Barcode Symbology Supported |
EAN-13 |
Barcode Symbology Supported |
EAN-14 |
Barcode Symbology Supported |
EAN-8 |
Barcode Symbology Supported |
GS1 DataBar |
Maximum Print Width |
103.89 mm (4.09") |
Recommended Use |
RFID Label Print |
Features |
RFID Reader |
Features |
Element Energy Equalizer |
Features |
Tear-off |
Encoding Technology |
RFID Encoder |
Print Color Capability |
Monochrome |
Real Time Clock |
Yes |
Maximum Print Resolution (dpi) |
300 |
