Display & Graphics |
Display Screen |
Yes |
Screen Size |
10.9 cm (4.3") |
Display Screen Type |
LCD |
Fonts & Emulation |
Language Emulation |
EZPL |
Language Emulation |
ZPL II |
Language Emulation |
ZPL |
Language Emulation |
ZBI |
Language Emulation |
XML |
Language Emulation |
EPL2 |
Language Emulation |
EPL |
Interfaces/Ports |
USB |
Yes |
Serial Port |
Yes |
USB Host |
Yes |
Media Types & Handling |
Media Thickness |
4826 µm |
Maximum Roll Diameter |
127 mm |
Media Type |
Wristband |
Media Type |
Black Mark |
Media Type |
Continuous Receipt |
Media Type |
Continuous Roll |
Media Type |
Die-cut Label |
Media Type |
Fanfold |
Media Type |
Gap |
Media Type |
Label |
Media Type |
Receipt |
Media Type |
Reflective |
Media Type |
Roll Fed |
Media Type |
Tag |
Media Type |
Tag Stock |
Media Sensor |
Full Width Sensor |
Media Sensor |
Multi-position Transmissive/Gap Sensor |
Media Sensor |
Moveable Reflective/Black Mark Sensor |
Maximum Label Width |
118 mm |
Maximum Label Length |
991 mm |
Memory |
Standard Memory |
256 MB |
Miscellaneous |
Platform Supported |
PC |
Platform Supported |
iOS |
Platform Supported |
Android |
Environmentally Friendly |
Yes |
Cables Included |
AC |
Cables Included |
USB |
Energy Star |
Yes |
Power Cable Localization |
UK |
Power Cable Localization |
JP |
Power Cable Localization |
AUS |
Power Cable Localization |
EU |
Power Adapter Included |
Yes |
Environmental Compliance |
Restriction of Hazardous Substances (RoHS) |
Network & Communication |
Bluetooth |
Yes |
Ethernet |
Yes |
Ethernet Technology |
Ethernet |
Physical Characteristics |
Weight (Approximate) |
2.49 kg |
Height |
190.5 mm |
Width |
203.2 mm |
Depth |
266.7 mm |
Power Description |
Input Voltage |
120 V AC |
Input Voltage |
230 V AC |
Power Source |
AC Supply |
Technical Information |
Application/Usage |
Desktop |
Barcode Symbology Supported |
Industrial 2 of 5 |
Barcode Symbology Supported |
Maxi Code |
Barcode Symbology Supported |
Micro PDF |
Barcode Symbology Supported |
MSI |
Barcode Symbology Supported |
Code 128 |
Barcode Symbology Supported |
Code 11 |
Barcode Symbology Supported |
Codablock |
Barcode Symbology Supported |
Codabar |
Barcode Symbology Supported |
AZTEC |
Barcode Symbology Supported |
PDF417 |
Barcode Symbology Supported |
Plessey |
Barcode Symbology Supported |
POSTNET |
Barcode Symbology Supported |
QR Code |
Barcode Symbology Supported |
Standard 2 of 5 |
Barcode Symbology Supported |
UPC 2 or 5 Digit Extension |
Barcode Symbology Supported |
Code 39 |
Barcode Symbology Supported |
Code 49 |
Barcode Symbology Supported |
Code 93 |
Barcode Symbology Supported |
Data Matrix |
Barcode Symbology Supported |
EAN With 2 or 5 Digit Extension |
Barcode Symbology Supported |
EAN-13 |
Barcode Symbology Supported |
EAN-8 |
Barcode Symbology Supported |
UPC-E |
Barcode Symbology Supported |
Interleaved 2 of 5 |
Barcode Symbology Supported |
ISBT-128 |
Barcode Symbology Supported |
LOGMARS |
Barcode Symbology Supported |
UPC-A |
Barcode Symbology Supported |
Planet Code |
Maximum Print Width |
104 mm (4.09") |
Recommended Use |
Label/Receipt Print |
Connectivity Technology |
Wired |
Features |
Dual Wall Frame |
Features |
Status Indicator |
Mobile Device Printing |
Yes |
Print Color Capability |
Monochrome |
Optional Connectivity |
Wireless LAN |
Real Time Clock |
Yes |
Maximum Print Resolution (dpi) |
203 |
