Display & Graphics |
Display Screen |
Yes |
Screen Size |
10.9 cm (4.3") |
Touchscreen |
Yes |
Display Screen Type |
LCD |
Fonts & Emulation |
Language Emulation |
ZBI 2.0 |
Language Emulation |
ZPL II |
Language Emulation |
ZPL |
Interfaces/Ports |
USB |
Yes |
Serial Port |
Yes |
USB Host |
Yes |
Media Types & Handling |
Media Thickness |
254 µm |
Media Type |
Black Mark |
Media Type |
Continuous Label |
Media Type |
Label |
Media Type |
Die-cut Label |
Media Sensor |
Reflective Media Sensor |
Media Sensor |
Transmissive Media Sensor |
Maximum Label Width |
114 mm |
Memory |
Standard Memory |
512 MB |
Miscellaneous |
Platform Supported |
PC |
Certifications & Standards |
Standards approvals: IEC 62368-1; EN 55032, Class A; EN 55035; EN 61000-3-2, 3-3 Product markings, but not limited to: cTUVus; CE; FCC A; ICES-003; VCCI; RCM; CCC; EAC; S-Mark; KCC; BSMI; India-BIS; In-Metro; Energy Star |
Energy Star |
Yes |
Power Cable Localization |
UK |
Power Cable Localization |
AUS |
Power Cable Localization |
EU |
Power Cable Localization |
JP |
Network & Communication |
Bluetooth |
Yes |
Ethernet |
Yes |
Ethernet Technology |
Fast Ethernet |
Physical Characteristics |
Weight (Approximate) |
14.70 kg |
Height |
300 mm |
Width |
245 mm |
Depth |
379 mm |
Power Description |
Power Source |
AC Supply |
Technical Information |
Application/Usage |
Desktop |
Barcode Symbology Supported |
Code 11 |
Barcode Symbology Supported |
Code 49 |
Barcode Symbology Supported |
Code 93 |
Barcode Symbology Supported |
Data Matrix |
Barcode Symbology Supported |
EAN-13 |
Barcode Symbology Supported |
EAN-8 |
Barcode Symbology Supported |
Code 128 (A/B/C) |
Barcode Symbology Supported |
Code 39 |
Barcode Symbology Supported |
Codablock |
Barcode Symbology Supported |
Codabar |
Barcode Symbology Supported |
AZTEC |
Barcode Symbology Supported |
Plessey |
Barcode Symbology Supported |
Planet Code |
Barcode Symbology Supported |
PDF417 |
Barcode Symbology Supported |
MSI |
Barcode Symbology Supported |
Micro PDF |
Barcode Symbology Supported |
Maxi Code |
Barcode Symbology Supported |
LOGMARS |
Barcode Symbology Supported |
ISBT-128 |
Barcode Symbology Supported |
Interleaved 2 of 5 |
Barcode Symbology Supported |
POSTNET |
Barcode Symbology Supported |
QR Code |
Barcode Symbology Supported |
RSS-14 |
Barcode Symbology Supported |
Standard 2 of 5 |
Barcode Symbology Supported |
TLC 39 |
Barcode Symbology Supported |
UCC Case Codes |
Barcode Symbology Supported |
UPC-A |
Barcode Symbology Supported |
UPC-A with EAN 2 or 5 Digit Extension |
Barcode Symbology Supported |
UPC-E |
Barcode Symbology Supported |
Industrial 2 of 5 |
Maximum Print Width |
103.89 mm (4.09") |
Recommended Use |
Label Print |
Connectivity Technology |
Wired & Wireless |
Features |
LCD Display |
Mobile Device Printing |
Yes |
Print Color Capability |
Monochrome |
Maximum Print Length |
3.99 m |
Character Sets |
Unicode |
Character Sets |
850 |
Optional Connectivity |
Parallel |
Optional Connectivity |
Wireless LAN |
Real Time Clock |
Yes |
Maximum Print Resolution (dpi) |
203 |
