| Cutter |
| Cutter |
Yes |
| Cutter Type |
Guillotine |
| Display & Graphics |
| Display Screen |
Yes |
| Screen Size |
10.9 cm (4.3") |
| Touchscreen |
Yes |
| Display Screen Type |
LCD |
| Fonts & Emulation |
| Language Emulation |
ZPL II |
| Language Emulation |
ZPL |
| Language Emulation |
EZPL |
| Language Emulation |
ZBI 2.0 |
| Interfaces/Ports |
| USB |
Yes |
| Serial Port |
Yes |
| USB Host |
Yes |
| Media Types & Handling |
| Media Thickness |
250 µm |
| Maximum Roll Diameter |
203.20 mm |
| Media Type |
Continuous Label |
| Media Type |
Notch |
| Media Type |
Label |
| Media Type |
Die-cut Label |
| Media Type |
Continuous Paper |
| Media Type |
Black Mark |
| Media Sensor |
Reflective Media Sensor |
| Media Sensor |
Transmissive Media Sensor |
| Maximum Label Width |
108 mm |
| Maximum Label Length |
508 mm |
| Memory |
| Standard Memory |
256 MB |
| Miscellaneous |
| Platform Supported |
PC |
| Certifications & Standards |
- TUVus
- CE Marking
- FCC-B
- ICES-003
- VCCI
- C-Tick
- NOM
- S-Mark (Arg)
- CCC
- CU
- BSMI
- KCC
- SABS
- IN-Metro
|
| Energy Star |
Yes |
| Power Cable Localization |
TW |
| Network & Communication |
| Bluetooth |
Yes |
| Ethernet |
Yes |
| Ethernet Technology |
Fast Ethernet |
| RFID |
Yes |
| Network Ready |
Yes |
| Near Field Communication (NFC) |
Yes |
| Physical Characteristics |
| Weight (Approximate) |
16.33 kg |
| Height |
323.9 mm |
| Width |
269.2 mm |
| Depth |
495.3 mm |
| Power Description |
| Power Source |
AC Supply |
| Frequency |
60 Hz |
| Frequency |
50 Hz |
| Technical Information |
| Application/Usage |
Industrial |
| Barcode Symbology Supported |
Code 128-B |
| Barcode Symbology Supported |
Code 128-C |
| Barcode Symbology Supported |
Code 39 |
| Barcode Symbology Supported |
Code 49 |
| Barcode Symbology Supported |
Code 93 |
| Barcode Symbology Supported |
Data Matrix |
| Barcode Symbology Supported |
EAN With 2 and 5 Digit Extension |
| Barcode Symbology Supported |
EAN-13 |
| Barcode Symbology Supported |
EAN-8 |
| Barcode Symbology Supported |
Industrial 2 of 5 |
| Barcode Symbology Supported |
Interleaved 2 of 5 |
| Barcode Symbology Supported |
ISBT-128 |
| Barcode Symbology Supported |
LOGMARS |
| Barcode Symbology Supported |
Maxi Code |
| Barcode Symbology Supported |
Micro PDF |
| Barcode Symbology Supported |
MSI |
| Barcode Symbology Supported |
Codabar |
| Barcode Symbology Supported |
Planet Code |
| Barcode Symbology Supported |
Plessey |
| Barcode Symbology Supported |
POSTNET |
| Barcode Symbology Supported |
QR Code |
| Barcode Symbology Supported |
RSS-14 |
| Barcode Symbology Supported |
Standard 2 of 5 |
| Barcode Symbology Supported |
TLC 39 |
| Barcode Symbology Supported |
UPC |
| Barcode Symbology Supported |
UPC-A |
| Barcode Symbology Supported |
UPC-E |
| Barcode Symbology Supported |
Code 128-A |
| Barcode Symbology Supported |
Code 11 |
| Barcode Symbology Supported |
Codablock |
| Barcode Symbology Supported |
UCC Case Codes |
| Barcode Symbology Supported |
PDF417 |
| Barcode Symbology Supported |
Aztec Code |
| Maximum Print Width |
103.89 mm (4.09") |
| Recommended Use |
Label Print |
| Connectivity Technology |
Wired & Wireless |
| Features |
Rugged |
| Features |
Bi-color LED |
| Mobile Device Printing |
Yes |
| Print Color Capability |
Monochrome |
| Maximum Print Length |
990.60 mm |
| Real Time Clock |
Yes |
| Maximum Print Resolution (dpi) |
600 |
